Exam-Style Questions.Problems adapted from questions set for previous Mathematics exams. |
1. | GCSE Higher |
The diagram shows a right-angled triangle and a semicircle. The straight side of the semicircle is the same length as the longest side of the triangle.
Work out the area of the semicircle.
Give your answer correct to 3 significant figures.
You must show all your working.
2. | GCSE Higher |
The diagram shows a sector of a circle, centre O, with one angle shown as being 110°. If the radius of the circle is 8cm calculate:
(a) The area of the shaded area.
(b) The perimeter of the shaded area.
3. | GCSE Higher |
A yellow equilateral triangle has been painted on a purple sector. The side OC is 20cm and OA is 12cm. Calculate the area of the purple region ABCD as a percentage of the area of the whole sector OCD.
The diagram is not drawn to scale.
4. | GCSE Higher |
The diagram shows a sector of a circle with sector angle 160° and radius 18 cm.
A chord divides the area of the sector into a yellow triangle and a blue segment. Calculate the area of the blue segment.
5. | IGCSE Extended |
A circle is drawn inside a square so that it touches all four sides of the square.
(a) If the sides of the square are each \(k\) mm in length and the area of the red shaded region is \(A\) mm2 show that:
$$4A=4k^2-\pi k^2$$(b) Make \(k\) the subject of the formula \(4A=4k^2-\pi k^2\)
6. | GCSE Higher |
OAB is a sector of a circle with centre O and radius 10 cm.
The length of the arc from A to B is 15cm.
Calculate the are of the sector. Give your answer correct to 3 significant figures.
7. | GCSE Higher |
This draft emoji design (not drawn to scale) includes a circle and a kite.
AB and AC are both tangents to the circle centre O.
The radius of the circle is 7cm. The dashed line AO is 12cm.
Calculate the length of the arc BDC.
8. | GCSE Higher |
Three crayons are held together with an elastic band. The diagram below shows the end of the crayons and the elastic band.
Each of the crayons has diameter of 10 mm. Find the length of the elastic band in this position
9. | IB Standard |
The following diagram shows a circle with centre O and radius 9 cm.
The points A, B and C lie on the circumference of the circle, and AÔC = 1.2 radians.
(a) Find the length of the arc ABC.
(b) Find the perimeter of the minor sector OAC.
(c) Find the area of the minor sector OAC.
10. | GCSE Higher |
Two identical small yellow circles are drawn inside one large circle, as shown in the diagram. The centres of the small circles lie on the diameter of the large circle. The part of the large circle that is outside both small circles is painted red.
Find the fraction of the large circle that is painted red.
If you would like space on the right of the question to write out the solution try this Thinning Feature. It will collapse the text into the left half of your screen but large diagrams will remain unchanged.
The exam-style questions appearing on this site are based on those set in previous examinations (or sample assessment papers for future examinations) by the major examination boards. The wording, diagrams and figures used in these questions have been changed from the originals so that students can have fresh, relevant problem solving practice even if they have previously worked through the related exam paper.
